CEF69 Frameset Kit Specification
A full-carbon enduro frame package supplied with the Bafang power system, battery and the core installation components required for a custom build.
Package note: Headset is included. Rear shock is not included.
- Frame
- TORAY T700/T800 full-carbon construction, UD finish
- Frame weight
- Approximately 2400g +/- 40g for size M
- Available sizes
- S, M and L
- Color
- Matt Black
- Motor
- Bafang M510 250W, M560 500W or M560 750W
- Display
- Bafang C030
- Battery
- 48V 17.4Ah / 835Wh
- Charger
- 3A charger
- Included controls
- Crankset, 36T chainring, speed sensor, EB-BUS and required cables
- Headset
- Included, 52mm upper / 52mm lower
- Rear shock
- Not included; 205mm eye-to-eye, 55-65mm shock travel compatible
- Front travel
- 180mm
- Rear travel
- 150-180mm platform
- Rear axle
- 148 x 12mm thru axle
- Brake mount
- Disc brake, 180mm
- Maximum tire
- 29 x 2.6 or 27.5 x 2.8
- Shipping
- Standard shipping included; air shipping available for +$200
